Client: METEC Design and Construction Engineers India Private Limited
Technologies Deployed
Completed Installation
Layerix completed the installation work described on this page. The quantities below are taken from the supplied BOQ and should be aligned with the approved as-built schedule if any final installed quantities changed during delivery.
About METEC Design & Construction Engineers
METEC Design and Construction Engineers India Private Limited describes itself as an engineering and MEP contracting company delivering design, supply, installation, testing and commissioning services across multiple engineering systems.
For METEC, Layerix completed a data networking and telecommunication installation spanning structured copper cabling, single-mode fibre-optic infrastructure, patch panels, equipment racks, network certification scope, CCTV installation and HDMI cabling.
Company reference: metecdesign.com
Project Scope — Copper, Fibre & Network Equipment Infrastructure
Layerix delivered the complete installation across the listed data networking and telecommunication systems. The work brought together Cat 6A data outlets, the fibre-optic backbone, termination and patching hardware, distributed network racks, network certification, CCTV and AV cabling.
- Data outlets: 900 Cat 6A RJ-45 information outlets and 900 two-metre patch cords.
- Fibre backbone: 2,450 metres of 12-core OS2 single-mode armoured fibre-optic cable, with adaptors, patch cords and termination panels.
- Patch panels: 15 CommScope modular panels across 24-port and 48-port configurations.
- Equipment locations: 13 network racks, including floor-standing, indoor wall-mounted and outdoor wall-mounted configurations.
- Additional systems: network scanning and certification for 500 points, CCTV installation/configuration/ support for 114 units, and HDMI cabling.
Completed Work — Installed Systems & Components
The completed installation covered the following systems and quantities recorded in the supplied BOQ.
Cat 6A Structured Cabling
- ▸900 Cat 6A information outlets for data (RJ-45, blue)
- ▸900 Cat 6A patch cords, 2 metres long
- ▸200 duplex-shuttered British-style faceplates
- ▸160 single-shuttered British-style faceplates
- ▸105 coils of Cat 6A 4-pair network cable, 305 metres per coil
- ▸Four coils of armoured Cat 6A 4-pair network cable, 305 metres per coil
Fibre-Optic Backbone & Termination
- ▸2,450 metres of 12-core OS2 single-mode armoured fibre-optic cable
- ▸ECSS (Electro Chrome Coated Steel) armouring and loose-tube construction as specified
- ▸50 OS2 duplex adaptors and fibre patch-cord assemblies
- ▸Nine 1U, 12-port FMS fibre-optic termination panels
- ▸Three 1U, 48-port FMS fibre-optic termination panels
Patch Panels & Network Racks
- ▸Eight CommScope M2000 U/UTP modular 1U, 24-port patch panels
- ▸Seven CommScope M2000 U/UTP modular 2U, 48-port patch panels
- ▸One floor-standing, two-side-accessible rack (42U/45U as stated in the schedule) with PDU and ventilation fan
- ▸Three 12U wall-mounted racks with PDU and ventilation fan
- ▸Eight 15U wall-mounted racks with PDU and ventilation fan
- ▸One 12U outdoor wall-mounted rack with PDU and ventilation fan
Certification, CCTV & AV Cabling
- ▸Network scanning and certification for 500 points
- ▸CCTV installation, configuration and support for 114 units
- ▸Five sets of 10-metre HDMI cables
- ▸Ten sets of 15-metre HDMI cables
- ▸Two sets of 20-metre HDMI cables
Installation Delivery — From Passive Cabling to System Integration
The completed work covered three connected packages: structured copper cabling, fibre and rack infrastructure, and network certification/CCTV/HDMI cabling.
Establish the copper data outlet layer
Layerix installed the Cat 6A data outlet and passive cabling infrastructure, including patch cords, British-style faceplates, standard Cat 6A 4-pair cable and armoured Cat 6A cable for the listed work areas.
- ▸900 Cat 6A RJ-45 information outlets
- ▸900 two-metre Cat 6A patch cords
- ▸200 duplex and 160 single-shuttered faceplates
- ▸105 standard and four armoured Cat 6A cable coils, each 305 metres
Provide the specified fibre and equipment locations
Layerix installed the OS2 single-mode armoured fibre backbone, fibre adaptors and patch cords, FMS termination panels, CommScope modular patch panels, and floor-standing, wall-mounted and outdoor network racks with PDUs and ventilation fans as specified.
- ▸2,450 metres of 12-core OS2 armoured single-mode fibre
- ▸50 fibre adaptor and patch-cord assemblies
- ▸Twelve fibre termination panels across 12-port and 48-port configurations
- ▸Thirteen network racks across floor-standing, indoor wall-mounted and outdoor wall-mounted types
Testing and supporting the listed systems
The completed scope included network scanning and certification for the listed 500 points, CCTV installation/configuration/support for 114 units, and HDMI cable sets in 10-metre, 15-metre and 20-metre lengths.
- ▸Network scanning and certification — 500 points
- ▸CCTV installation, configuration and support — 114 units
- ▸Five 10-metre HDMI cable sets
- ▸Ten 15-metre HDMI cable sets and two 20-metre HDMI cable sets
Project at a Glance
Cat 6A RJ-45 information outlets
12-core OS2 armoured fibre cable
Floor-standing, wall-mounted and outdoor
CCTV installation, configuration and support
Quantities shown are based on the supplied BOQ; use the approved as-built schedule if final installed quantities differ.
Other Listed Components
A Structured Infrastructure Scope for METEC
The completed project brought together the passive network layer, fibre distribution, rack infrastructure, network certification scope, CCTV and HDMI cabling in one coordinated installation. The result is a structured physical infrastructure foundation for METEC’s data and connected systems.
Add approved project photographs, the installation location and completion date to strengthen the published case study. If the final as-built quantities differ from the BOQ, update the figures before publication.
About the Customer
METEC Design and Construction Engineers India Private Limited provides engineering and MEP contracting services. Visit the company website for its published service and company information.
Visit METEC Website ↗About Layerix Networking Experts
Layerix Networking Experts completed METEC’s structured network cabling and telecommunications installation, covering copper data outlets, fibre backbone and termination, network racks, patch panels, CCTV and HDMI cabling.
Key Results
900 Cat 6A information outlets for data (RJ-45, blue)
2,450 metres of 12-core OS2 single-mode armoured fibre-optic cable
50 OS2 duplex adaptors and fibre patch-cord assemblies
12 fibre-optic termination panels listed in 1U, 12-port and 48-port configurations
15 CommScope modular patch panels: eight 24-port panels and seven 48-port panels
900 Cat 6A patch cords, each 2 metres long, at workstation/telephone/machine side
360 British-style faceplates: 200 duplex and 160 single
Network scanning and certification for 500 points
13 network racks: one floor-standing rack, eleven indoor wall-mounted racks and one outdoor wall-mounted rack
CCTV installation, configuration and support for 114 units
